Drum Core
8x10
Drum Core > 8x10
Description
Size
Part Number
Description
Inductance 1KHz @ 0.3V
Current Rating
8x10
GT-010101
Choke 8x10 1.00mH / 450mA with 2pin Black Sleeve
1mH (± 10%)
400 ∼ 600mA
8x10
GT-010201
Choke 8x10 1.00mH / 450mA with 2pin Black Sleeve UL
1mH (± 10%)
400 ∼ 500mA
8x10
GT-010301
Choke 8x10 2.2mH / 350mA with 2pin Black Sleeve UL
2.2mH (± 10%)
200 ∼ 350mA
8x10
GT-010401
Choke 8x10 33mH / 50mA with 2pin Blue Sleeve UL
33mH (± 10%)
40 ∼ 80mA
8x10
GT-010501
Choke 8x10 47mH / 50mA with 2pin Grey Sleeve UL
47mH (± 10%)
30 ∼ 60mA
8x10
GT-010601
Choke 8x10 68mH / 50mA with 2pin Black Sleeve UL
68mH (± 10%)
30 ∼ 60mA
8x10
GT-010701
Choke 8x10 1mH / 100mA with 2pin Black Sleeve
1mH (± 10%)
80 ∼ 100mA
8x10
GT-010801
Choke 8x10 1.5mH / 400mA with 2pin Black Sleeve UL
1.5mH (± 10%)
200 ∼ 350mA
8x10
GT-010901
Choke 100uH / 600mA with 8x10 2pin Black Sleeve
100uH (± 10%)
500 ∼ 900mA
8x10
GT-011001
Choke 8x10 100uH / 1.5A with 2pin Black Sleeve
100uH (± 10%)
1A ∼ 1.5A
8x10
GT-011101
Choke 2.2mH / 500mA 8x10 2pin with Black Sleeve
2.2mH (± 10%)
80 ∼ 100mA
8x12
GT-011201
Choke 53uH 8x12 2 pin with Black Sleeve
53uH (± 10%)
3 ∼ 3.5A
8x10
GT-011301
Choke 8x10 1.00mH / 290mA with 2pin Black Sleeve
1mH (± 10%)
400 ∼ 600mA
8x10
GT-011401
Choke 8x10 3.3uH / 2A with 2pin Blk Sleeve (0.35mmx2)
3.3uH (± 10%)
1A ∼ 2A
8x10
GT-011501
Choke 8x10 220uH / 1.5A with 2pin Black Sleeve
220uH (± 10%)
1A ∼ 1.5A
8x10
GT-011502
Choke 8x10 220uH / 1.5A with 2pin Black Sleeve
220uH (± 10%)
1A ∼ 1.5A
8x10
GT-011601
Choke 8x10 68uH/2A with 2 Pin Black Sleeve
68uH (± 10%)
3 ∼ 3.5A
8x10
GT-011701
Choke 8x10 33uH/2A with 2 Pin Black Sleeve
33uH (± 10%)
1.5A ∼ 2A
8x10
GT-011801
Choke 8x10 30uH/500mA with 2 Pin Black Sleeve
30uH (± 10%)
900mA ∼ 1.2A
8x10
GT-011901
Choke 8x10 1.20mH / 400mA with 2pin Black Sleeve UL
1.2mH (± 10%)
200 ∼ 350mA
8x10
GT-012001
Choke 1.50mH / 350mA 8x10 with 2pin Black Sleeve
1.5mH (± 10%)
200 ∼ 350mA
