Common Mode > UU9.8
Description
| Size | Part Number | Description | Inductance 1KHz @ 0.3V | Current Rating | |
|---|---|---|---|---|---|
| UU9.8 | GT-080101 | Choke 8mH/350mA UU9.8 Vert. | (Min) 8mH | 500 ∼ 800mA | |
| UU9.8 | GT-080201 | Choke 22mH/150mA UU9.8 Vert. | (Min) 22mH | 200 ∼ 350mA | |
| UU9.8 | GT-080301 | Choke 30mH/120mA UU9.8 Vert. | (Min) 30mH | 100 ∼ 200mA | |
| UU9.8 | GT-080401 | Choke 2.2mH/350mA UU9.8 Vert. 4Pin | (Min) 2.2mH | 700mA ∼ 1A | |
| UU9.8 | GT-080701 | Choke 9.1mH/175mA UU9.8 Vert. 4Pin | (Min) 9H | 400 ∼ 500mA | |
| UU9.8 | GT-080901 | Choke 50mH / 3A UU9.8 Vert. 4Pin | (Min) 50mH | 400 ∼ 500mA | |
| * | UU9.8 | GT-080202 | Choke 22mH/150mA UU9.8 Hori. | (Min) 22mH | 200 ∼ 350mA |
